Product Reference Guide 61
* Do not leave floating, see "RS422 Full Duplex Interface" on page 66 for connection
details.
NOTE
Outputs +V Power Source - Outputs
-V Power Reference - Outputs
O1+ Output 1 + opto-isolated and polarity sensitive
O1- Output 1 - opto-isolated and polarity sensitive
O2+ Output 2 + opto-isolated and polarity sensitive
O2- Output 2 - opto-isolated and polarity sensitive
O3A
Output 3 - opto-isolated (only available through
CBX5
00)
Auxiliary Interface TX Transmit Data
RX Receive Data
SGND Auxiliary Interface Signal Ground
ID-NET REF Network Reference
ID+ ID-NET network data +
ID- ID-NET network data -
Shield Network Cable Shield
Main Interface
RS232 TX
RX
-
-
SGND
RS422 Full Duplex TX+
*RX+
TX-
*RX-
SGND
Group Label Description
To avoid electromagnetic interference when the reader is connected to a CBX connec-
tion box, verify the jumper positions in the CBX as indicated in its Installation Manual.
