Table 40. System setup options—Display menu
Display
Multi-Display Enable or disables Multi-Display,
NOTE: This feature has to be enabled for Windows 7 or later, and not
applciable to other operating systems.
By default, Enable Multi-Display is enabled.
Primary Video Slot Determines which video controller to be the primary display when multiple
controllers are available in the system.
By default, Auto is enabled.
Full Screen Logo Enable or disable full screen logo.
By default, the option is not enabled.
Table 41. System setup options—Connection menu
Connection
Network Controller Configuration
Integrated NIC Enable or disable on-board LAN Controller.
By default, Enabled with PXE is enabled.
Integrated NIC2
By default, Enabled is enabled.
Enable UEFI Network Stack Enable or disable installation of UEFI networking protocols.
By default, the Auto Enabled option is enabled.
HTTPs Boot Feature
HTTPs Boot Enable or disable the HTTPs Boot feature.
By default, the HTTPs Boot option is disabled.
HTTPs Boot Modes
By default, the Auto Mode option is disabled.
Table 42. System setup options—Power menu
Power
USB PowerShare
Enable USB PowerShare Enables external devices (such as phones and portable music players) to be
charged using stored system battery. Devices must be connected to system
using designated USB PowerShare ports.
By default, the Enable USB PowerShare is enabled.
Thermal Management Enables to cool the fan and processor heat management to adjust the system
performance, noise, and temperature.
By default, the Optimized option is enabled.
Lower PCIe Slot Zone Allows increasing target fan speed on Lower PCIe Slot Zone giving a higher
performance.
CPU/Memory Zone Allows increasing target fan speed on CPU/Memory Zone giving a higher
performance.
USB Wake Support
Enable USB Wake Support When enabled, the USB devices like a mouse or keyboard can be used to wake
the system from Standby, Hibernate, and Power Off.
NOTE: This feature requires Deep Sleep Control to be disabled.
164 BIOS Setup
