Delphin ProfiMessage User Manual

ProfiMessage
l bool:Trueorfalse
l float:afloatingpointnumberorafraction
l int:aninteger
Constants
l Constantsareconsideredasintegersifenteredwithoutadecimalpoint
l Constantsmustbegivenwithadecimalpointandnotacomma,regardlessof
thecountrysettingofthecomputerandtheDataServiceConfigurator.
4.7.17 Batchalarms
Thissoftwarechannelmonitorschannelswithbooleanoutputsignalstogeneratea
commonalarm.ItsoutputhasanONstatewhenoneofthesources(Monitored
channels) hasanON-state(logicalORlink).
Latching:Thealarmislatched(continuestoalarm)evenwhenthealarmcondition
isnolongermet.Thealarmhastoberesetbyaresetevent.IftheLatching option
isnotselected,theoutputforthebatchalarmchanneltakesthestateofthelinked
sources.
EnablingLatchingchangesReset trigger for latching.Thealarmresetswhena
reseteventoccurs,e.g.arisingedgeinthegivenchannel.TheReset priority
optioncausesanalarmtoresetwhenthealarmconditionisstillmet.
ReferalsotoTriggeroptions.
Method
l SelectoneorseveralchannelstotriggerabatchalarmfromtheAvailable
channels fieldandclicktoaccepttheselection.
l
SelectoneorseveralchannelsfromMonitored channels andclicktoremove
theselection.
4.7.18 Shiftregister
Theslidertaballowsyoutotransmitvalueswithdelay.
GivetheSourcewhichistobedelayedandhowmanyvalues(Number of values)
thedelayistoaffect.Anentryfrom100allowsthe101value,whenthereare100
values,tocausethefirstreadvaluetobeoutput.100valuesarealways
“reserved”.
UsetheTriggertoestablishthatthedelayonlyoccursifthetriggereventoccurs.
Resetcancelsthedelay.
ReferalsotoTriggeroptions.
137
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
