ProfiMessage
2 Getting started
Thissectionoutlines:
l HowtoestablishaconnectionbetweenaPCandthedevice.
l Thesettingsrequiredtoacquiremeasurementsignalsfromthedevice.
FordetailedinformationseetheseSections:
l TheSectionProfiMessagedisplaysandconnectionsgivesyouanoverview
ofalltheinterfaces/connections/portsandLEDs.
l TheSectionConfigurationandoperationexplainsthedifferentoptionsforset-
tingupthedeviceformeasurementtasks.TheSectiondescribesspecificset-
tingsforProfiMessagedevices.Theavailablesettingsforalldevicesare
availableunderCommondevicesettings.
SeealsoConfigurationandoperation.
l TheSectiononExamplesofconnectionsshowsyoutheoptionsforcon-
nectingstandardsensorsandactuatorsandhowtoconfigurethem.
l TheSectiononMeasurementtechnologynotescontainsgeneralinformation
andrecommendationsonapplyingmeasurementtechnology.
l TechnicaldataisavailableintheSectiononTechnicalspecifications.
2.1 Installing programs
You need administrator rights to install the pro-
gram.
InstalltheProfiSignalCD.Duringtheinstallation,ensurethatyouinstallthe
DataService Configuratorasaprogram(andnotasaservice).
Afterdefaultinstallationyouwillfindbothofthesesymbolsonyourdesktop:
TheprogramworksDataServiceConfiguratorfromDelphinasalinkbetweenthe
PCandthemeasuringhardware.AlldevicesareimmediatelyconfiguredinDataSer-
viceConfigurator.
TheProfiSignalprogramevaluatesanddisplaysmeasurementdata.
13
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
