Delphin ProfiMessage User Manual

ProfiMessage
Selecttheunitofmeasurementinwhichthetemperatureistobedisplayed.Con-
versionisperformedautomaticallywithinthedevice.
°C:DegreesCelsius
K:Kelvin
°F:DegreesFahrenheit
R:Rankine
°R:DegreesRéaumur
Scaling
Enterthevalidrangeforsensorsignals.Thespecifiedrange(intheexample-270
°Cto+1372°C)isusedasthedefaultforthedisplayareaforgraphicsinProfiSig-
nal.Thechannelreceivesthestatus"scalerangeoverrun"for"scalerangeunder-
run"whennotwithintherange.Channelstatusvaluesareavailableinstatus
monitoring.
Info
EnterthecompensationtobeusedintheAdvanced settingstab.
RefertoSettingsforalldialogues.
4.6.3.7 Phprobesensortype

ThissensortypedeterminesthepHvaluefromthevoltageofthepHprobeinmV
andthetemperaturein°CofthereferencejunctionviatheNernstfactor.
88
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
