Delphin ProfiMessage User Manual

ProfiMessage
Outputrangeis0…10V,max.loadis4mA(min.2.5kΩ).
The'-'connectorisconnectedat1kΩtotheinternalanalogueearthpoint.
Digital inputs / counters
Squaresignals/pulsesfrom5V/12Vor24Vcanbeconnected.
Low-levelis<1.5V;high-levelis>3.5V;common'-'connector,potentialisol-
ation.
Frequencymeasurementforsignalsfrom0.2Hzto30kHz.
Digital outputs
Switchingvoltageatamax.of50VDC.Switchingcurrentatamax.:2.5ADC.
Common'+'connector.Potentialisolation.
Shielded cabling
TheI/OmoduleenablesmeasurementinthesignalrangeDC…8kHz.This
requirestheuseofshielded(single-sidedshieldingconnectedtoprotectiveearth)
ortwistedpaircables.
Sensors
Informationonconnectingspecialsensorsisavailableinthe"Applicationsusing
AMDT"manual.
9.1.3 Connectorpanel(laboratory)

Information on connections
RefertoConnectorpanel(industry).
9.1.4 Blockdiagrams
Blockdiagramforhardware
233
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
