Delphin ProfiMessage User Manual

ProfiMessage
Outputisalwaysintherange0...10V.
Main settings tab

Source
Sourceselectsfromvarioussignalsources:
l Application:OutputdataiscontrolledviaaProfiSignalapplication.
l Channel:OutputdataiscontrolledviaaDataServicechannel.
l Manual value:Outputisenteredanddeterminedmanually.
Scaling
Definesthephysicalbasisfortheoutputunitofmeasurement.Intheexample0...
100isassignedtheoutputvalue0...10V.
9.3.1.7 Configuration/settingsfordigitalinput
Referalsotothetechnicalspecificationsofdigitaloutputs.
Main settings tab
300
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
