4.8.2.2 CANbuschannel
ACANbusinputchannelisidentifiedby andaCANbusoutputsignalby .
CAN-buschannelsareavailableonlywhenaCANconnectionandCANprotocol
havebeenconfigured.SelectCreatechannel→ CANbusinputorCANbusoutput
intheCANprotocolcontextmenu( ,CANRAWprotocol),tocreatechannels.

Double-clickaCANbuschannelentryorselectPropertiesfromthecontextmenuto
displaytheconfigurationdialogue.Thedatatobeentereddependsonthetypesig-
nalthatistobesenttoorreceivedfromtheCAN-bususer.(RefertoUsingchannel
asanoutput).Therefore,obtaininformationontheformatandsettingsofthesig-
nalbeforeenteringdatahere.
ReferalsotoSettingsforalldialogues.
