ProfiMessage
4.6.2 AMDTI/Omodule
TheAMDTI/Omoduleforvibrationmeasurementisdiscussedinaseparatesec-
tion.
RefertoAMDTI/Omodule.
Channelconfiguration/settingsaredescribedhere:AMDTI/Omodulesectioncon-
figurationandoperation.
4.6.3 Analogueinput
ConfigurationoptionsintheMain settingstabdependonthesensortype:
l Voltage,e.g.0…10V
l Resistance
l Current,e.g.4…20mA
l Resistancethermometer,e.g.Pt100
l Thermocouple,e.g.typeKNiCr-NiAl
l pHprobe
Info
ReferalsotoExamplesofconnectionsforinformationonthecon-
nectionofsensorsandMetrologicalinformationforbackground
informationonmetrologicalpractice.
Thedialoguehasadditionaltabs:
l Additionalsettings
l Measuringtimetab
80
