9.2.1.3 Signalsimulation
Insignalsimulation,thesignalsmeasuredbyanalogueinput1…8arediscarded
andreplacedbydemosignalscomputedbytheDSP.Thisoperatingmodeenables
userstoperformtestrunswithouthavingtoactuallyconnectsignals.Achoiceof
signalsandmodulationtypesareavailable.
Signal 1
Description:Harmonicsignal
Channel1…8:Sine,1000mVpp,50Hz
Timesignalandfrequencyspectrum:


Signal 2
Description:Signalwiththreefrequencycomponents
Channel1Sinewith3components,1000mVpp,100Hz/200mVpp,200Hz/40
mVpp,300Hz
Channel2...8with2...8-foldamplitude
Timesignalandfrequencyspectrum:
245
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
