AfterselectingSlave redundancy,Backup COM-Port showsthattheCOM2interface
isusedforbackups.
Slave redundancy canbeselectedonlywhenasecondinterfaceis
availableforbackupoperations.Asecondinterfacemustrunin
PROFIBUSmode.However,noPROFIBUSprotocolisallowedtobecon-
figuredtothisconnection.Thedialoguenotifiesofanyincorrectset-
tings.
Thesymbol isthendisplayedforthechannelfollowingconfiguration.Then
createandconfiguretherequiredPROFIBUSchannels(Signals).
4.8.3.2 PROFIBUSchannel
CreatingPROFIBUSchannelsrequirescreationofaCOMconnectioninthe
PROFIBUSinterfacemodeandofaPROFIBUSprotocol(subchannel).SelectCreate
channel→ PROFIBUS inputorPROFIBUS outputfromthecontextmenuofthe
PROFIBUSprotocol( ,PROFIBUSprotocol)inordertocreatechannelsforyour
PROFIBUSsignals.APROFIBUSinputchannelisidentifiedby ,andaPROFIBUS
outputchannelby .

Double-clickaPROFIBUSchannelorselectPropertiesfromthecontextmenutodis-
playtheconfigurationdialogue.Thedatatobeentereddependsonthesignaltype
thatistobesenttoorreceivedfromthePROFIBUSuser.(RefertoUsingchannelas
anoutput).Therefore,obtaininformationontheformatandsettingsofrelevant
PROFIBUSsignalsbeforeenteringdatahere.
ReferalsotoSettingsforalldialogues.
Main settings tab
179
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
