Delphin ProfiMessage User Manual

ProfiMessage
channel(blue curve).Arisingedgeintheresetchannel(bright green curve)
resetsthecountertozero.TheGenerateintermediatevaluesoptionisenabledso
allnewcounterreadingsareoutputimmediately.
Example of value transfer
Duringtheperiodofvaluetransfer(light blue curve),thecountervalueisout-
put.TheoptionGenerate intermediate valuesisdisabled,sonointermediateval-
uesareoutput.
4.7.31 Timedelay
Thissoftwarechannelallowsyoutochangethetimeof(digital)sourcesignals.
Thispermits,forexample,newtriggertimepointstobecreatedforasubsequent
channelordefinedsignalstobegeneratedforoutputtingtotheprocess.APickup
delaymodetemporallycompressesthesourcesignalandaDropout delaytem-
porallyexpandsasignal.
158
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
