Delphin ProfiMessage User Manual

ProfiMessage
Thecounter(greencurve)decreasesbyoneforeachedgefromthesourcechan-
nel(orange curve) until the reset trigger becomes active.TheGenerate
intermediate values optionisenabled,soallnewcounterreadingsareoutput
immediately.

Exampleforupwardsanddownwardscounter
The counter (greencurve) increases by one at each rising edge of the
source channel (orangecurve) and decreases by one at each falling edge
of the source channel (bluecurve)untiltheresettriggerbecomesactive.The
Generate intermediate values optionisenabled,soallnewcounterreadingsare
outputimmediately.
Exampleforgeneratingintermediatevalues

Thecounter(green curve)increasesbyoneateachrisingedgeofthesource
channel(orange curve)anddecreasesbyoneateachfallingedgeofthesource
157
