Delphin ProfiMessage User Manual

ProfiMessage
TheDSPdetermines(finds)theminimumvalue(orlowestnegativevalue)ofthe
timesignalanddeliverstheamplitudevalue.

Smooth curve / Discard anomaliesplating
Smoothcurvespriortodeterminingcharacteristicvaluesmaybeapplicabletoperi-
odicsignalsthathavenoiseordistortions.Thesetwosettingsareavailableinthe
Optionstab:

9.2.5.2 Peak-to-peakcharacteristicvalue
TheDSPcalculatesthepeak-to-peakvalueofthetimesignal,i.e.thedifference
betweenthemostpositiveandmostnegativeamplitudevalues.

Options Smooth curve/Discard anomalies
Smoothcurvespriortodeterminingcharacteristicvaluesmaybeapplicabletoperi-
odicsignalsthathavenoiseordistortions.Thesetwosettingsareavailableinthe
Optionstab:
262
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
