Delphin ProfiMessage User Manual

ProfiMessage
>1…10kHz:±5Hz
>10…30kHz:±10Hz
Counterwidth 16bit
Potentialisolation 2.5kV
Reversepolarityprotection 1kV
Digitaloutputs
Numberofoutputs
DIOT:16
IOIT:1
OTPT:24
Switchingvoltage max.50VDC
Switchingcurrent max.2.5ADC
Flybackdiode Integrated
Potentialisolation 2.5kV
8.4 ADFT I/O module
Analogue inputs

Numberofinputs 8
Connections Terminals,max.diameter2.5mm2
Voltagemeasuringranges ±156mVto±10V
Currentmeasurementranges
±20mA,0...20mAand4...20mA
Currentmeasurementrequiresaloadres-
istanceof10...500Ω
Measurementfrequencyrange
(-3dB)
0…4000Hz
Samplingrate
10...5000Hz,in10stages,individually
adjustableforeachchannel.
Channelswiththesamesamplingratecan
besampledsimultaneously.
Samplingrate 10...8000measurements/s
Resolution 14bits(approx.1.2mVinthe10Vrange)
AC/DCcoupling
DCcouplingpreset,switchingviaDIP
226
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
