4.6.3.1 Voltagesensortype

Theexamplemeans:0mVcorrespondsto0bar,5Vcorrespondsto10bar.
Mode
unipolar:Measuringonlypositivesignals.
bipolar:Measuringpositiveand/ornegativesignals.
Measuring range
Selectameasuringrangethatisequaltoorgreaterthanthesignalfromthe
sensororsignalsourcetopreventA/Dconverteroverload.Thechannelreceives
thestatus‘Measurementrangeoverrun/underrun’formeasurementsnotwithin
therange.Channelstatusvaluesareavailableinstatusmonitoring.
Scaling
Entertwopointsfromthesensor'scharacteristiccurve,ifpossible,thelowerand
uppervertexes.Foralinearcharacteristic,measurementvaluesarethencon-
vertedintotheunitofmeasurement(scaling)fromthesensor.Fornon-linearchar-
acteristics,useSensor compensation.RefertotabSensorcompensation.The
specifiedrange(intheexample0barto10bar)isusedasthedefaultforthe
ProfiSignalgraphicdisplayarea.Thechannelreceivesthestatus"scalerangeover-
run"for"scalerangeunderrun"whennotwithintherange.Channelstatusvalues
areavailableinstatusmonitoring.
