changedbyareset,i.e.afollow-upalarmmaytriggerduringtheconfiguredtime.
ReferalsotoTriggeroptions.
4.7.30 Counter
Thissoftwarechannelcountsevents.
ReferalsotoTriggeroptions.
Upward count trigger:Thechannel'scounterisincreasedbyoneattheselected
edge(Rising edge,Falling edge,Edges (both),Every highorEvery low)ofthespe-
cifiedchannel.
Downward count trigger:Thechannel'scounterisreducedbyoneattheselected
edge(Rising edge,Falling edge,Edges (both),Every highorEvery low)ofthespe-
cifiedchannel.
Reset trigger:Thechannel'scounterisoutputandresetinternallytozeroatthe
selectededge(Rising edge,Falling edgeorEdges (both)).WhenReset triggeris
enabled,thecounterisdisplayedonlyatareseteventunlesstheGenerate inter-
mediate values optionhasbeenenabled.
Generate intermediate values:Whenenabled,theresultsarealsooutputbetween
thereseteventsimmediatelyaftertheircalculation(witheverycounterchange).
Value output:Thechannel'scounterisoutputwiththeselectededge(Rising edge,
Falling edgeorEdges (both)).
Start value:Enablesyoutoindicateastartvalueforthecounter.Selectanavail-
ablechannelwhosevalueistobeoutputusingChannel,orenteraconstantvalue
(Manual value).SelectingApplicationenablestheoutputvaluetobemanuallyset
viatheDataServiceConfiguratororautomaticallysetviaaProfiSignalapplication.
Info
ForactivatingPersistenceintheAdditional settingstab,e.g.inthe
eventofpoweroutage,thelastcounterreadingissavedandcount-
ingresumesfromthispoint.ThechoiceforStart valueissettothe
application.
Example of upwards counter
