4.6.3.2 Resistancesensortype

Theexamplemeans:0degreescorrespondsto0ohms,4000ohmscorresponds
to270degrees.
Measuring range
Selectameasuringrangethatisequaltoorgreaterthantheresistancefromthe
sensortopreventA/Dconverteroverload.Thechannelreceivesthestatus‘Meas-
urementrangeoverrun/underrun’formeasurementsnotwithintherange.Chan-
nelstatusvaluesareavailableinstatusmonitoring.
Scaling
Entertwopointsfromthesensor'scharacteristiccurve,ifpossible,thelowerand
uppervertexes.Foralinearcharacteristic,measurementvaluesarethencon-
vertedintotheunitofmeasurement(scaling)fromthesensor.Fornon-linearchar-
acteristics,useSensor compensation.RefertotabSensorcompensation.The
specifiedrange(intheexample0degreesto270degrees)isusedasthedefault
fortheProfiSignalgraphicdisplayarea.Thechannelreceivesthestatus"scale
rangeoverrun"for"scalerangeunderrun"whennotwithintherange.Channel
statusvaluesareavailableinstatusmonitoring.
