ProfiMessage

7 RTS RequesttoSend(RS-232)

8 CTS CleartoSend(RS-232)

9 - Notconnected

3.5 I/O module connections (terminal blocks)

Devicescanbefittedwithdifferentmodules.Belowarethethewiringdia-

grams/terminalassignmentsforthevariousI/Omodules.

l AAST

l ADFT

l ADGT

l ADIT

l ADVT

l AMDT

l DIOT

l IOIT

l OTPT

3.5.1 AAST
