ProfiMessage
9 AMDT I/O module
ThissectionofthedocumentationdescribesusingandconfiguringtheAMDTI/O
module.
TheAMDTI/Omodulehasbeendesignedforvibrationmeasurement.TheI/Omod-
uleutilisesaDSP(digitalsignalprocessor).Theprocessor'sfirmware(=software
intheI/Omodule)enablesmanyfunctionsforsignalprocessing.
Thedocumentationisprovidedunderthefollowingheadingsforoptimumover-
view:
l Hardware
l Function
l Configurationandoperation
Therelevantsubjectscanbereaderindependentlyundertheirindividualsections.
Selectonlythesectionyourequire.
Thecontentisbasedonthefollowingversion:
l ProfiSignalCD:V3.1.4
l Devicefirmware:V232
l AMDTboard:V2.0x
l AMDTfirmware:V3.58
Copyright©2003-2012DelphinTechnologyAG.Allrightsreserved.
Thisdocument'scontent,especiallytext,images,andgraphicsareprotectedby
copyright.Whennototherwisestated,thecopyrightbelongstoDelphinTech-
nologyAG,Lustheide81,in51427BergischGladbach,Germany.
Allthetrademarksandbrandsusedinthismanualreferonlytotherespective
productortrademarkholder.DelphinTechnologyclaimsnorightsotherthan
thosetoitsowntrademarksandbrands.
9.1 Hardware
9.1.1 Projectplanninganddesign
TheProfiMessagesystemismadeupofabasedeviceandoptionalextension
devices(thegraphicshowsaProfiMessagesystem).Adevicecannotbeexten-
ded.
230
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
