Delphin ProfiMessage - External Switching

ProfiMessage

Twoswitchesrequireactivating.Analogueinput1islocatedontheright.
Switch position Function
OFF(up) ACcoupling
ON(down) DCcoupling
ACcouplingisbasedon0.1µF(50V)serialcapacitors–theseprovideahigh-
passcut-offfrequencyof4Hz.
9.1.6.2 Externalswitching
Thefollowingincludesexamplesofexternalswitching.
