Delphin ProfiMessage User Manual

ProfiMessage
Frequenciescanbemeasuredbetweenthelowerlimitat2*fs/nsandtheupper
limitatfs/10forselectedparameters(recordingparameters).Themeasurement
valueequals0beyondtheselimits.
Belowisthecorrespondingconfigurationdialogue(Main settingstab):

9.2.5.11 "Maximumvect.sum"characteristicvalue
TheDSPperformsvectoraladditionofallamplitudevaluesfromthetimesignalsof
twoconsecutivechannels(e.g.analogueinput1and2)andthendeterminesthe
maximum.Thecharacteristicvaluemustbesetforthefirstofthetwoconsecutive
channels.

Options Smooth curve/Discard anomalies
Smoothcurvespriortodeterminingcharacteristicvaluesmaybeapplicabletoperi-
odicsignalsthathavenoiseordistortions.Thesetwosettingsareavailableinthe
Optionstab:

9.2.5.12 "Artihm.averageofproduct”
TheDSPperformsmultiplicationofallamplitudevaluesfromthetimesignalsof
twoconsecutivechannels(e.g.analogueinput1and2)andthendeterminesthe
arithmeticalaverage.Thecharacteristicvaluemustbesetforthefirstofthetwo
consecutivechannels.
269
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
