Delphin ProfiMessage User Manual

ProfiMessage
bipolar:Measuringpositiveand/ornegativesignals.
Load
Entertheloadresistancebeingused.Delphinoffersvariousloadresistancesfor
thecurrentmeasurement.Contactustoobtainasuitableresistance.
Current measurement is not possible without load res-
istance.
Scaling
Entertwopointsfromthesensor'scharacteristiccurve,ifpossible,thelowerand
uppervertexes.Foralinearcharacteristic,measurementvaluesarethencon-
vertedintotheunitofmeasurement(scaling)fromthesensor.Fornon-linearchar-
acteristics,useSensor compensation.RefertotabSensorcompensation.The
specifiedrange(intheexample0l/hto1000l/h)isusedasthedefaultforthe
ProfiSignalgraphicdisplayarea.Thechannelreceivesthestatus"scalerangeover-
run"for"scalerangeunderrun"whennotwithintherange.Channelstatusvalues
areavailableinstatusmonitoring.
4.6.3.5 Resistancethermometersensortype

85
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
