ProfiMessage
4.7.2 Operatinghourscounter
Thissoftwarechannelregistersthetimeperiodduringwhichthesourcehasan
activelevel.Whenthelevelbecomesinactive,thetimeperiodisaddedtotheexist-
ingtimeperiod.
High level / Low level:Setstheactivelevelofthesource.
Theoperatinghourscounterretainsitsvalueevenwhenthescaleis
altered.
EnableResetandconfigureachannelandthetrigger(edge,level)toresetthe
operatinghourscounter.
ReferalsotoTriggeroptions.
Ifthesourcehasanactivelevelwhentheresetsignaloccurs,theoperatinghours
counterisresettozeroonlyafterthesourcebecomesinactiveagain.
4.7.3 Differentiator
Thissoftwarechannelcalculatestheratioofthedifferencebetweentwovalues
fromthesourcechanneltothedifferencebetweentheirtimestampsinrelationto
thetimebase:
Differential=(Δvalue/Δtimestamp)*timebase
ReferalsototheAdditionalSettingstab
Time base:Enterthetimebaseforthecalculation.Thedefaultis1000ms.
EnabletheTrigger ifthecalculationistobetriggeredbyspecificevents.Thedif-
ferentialbetweensuccessivetriggereventsisthencalculated.
ReferalsotoTriggeroptions.
4.7.4 Event
Dialogistnochnichtbeschrieben!BeschreibungfolgtinKürze.
4.7.5 Flip-flop
Thissoftwarechannelfunctionsasahardwareflip-flop.
Selectthetypeofflip-flopintheModefield.Adiagramisdisplayeddependingon
theselection.Variousinputsareavailable.Disableanyunnecessaryinputs.
97
