ProfiMessage
Input value A Input value B Input value C Output value
H H L L
H H H L
Status table equivalence
Input value A Input value B Input value C Output value
L L L H
L L H L
L H L L
L H H H
H L L L
H L H H
H H L H
H H H H
4.7.12 Markers
Thissoftwarechannelprovidesacontroloptionthatenableseithermanualcontrol
overtheprocessesinadeviceviatheDataServiceConfiguratororautomatedcon-
trolviaaProfiSignalapplication.
SignalflowisviaamarkerchannelfromtheDataServiceConfiguratororaProfiSig-
nalapplicationtowardsthedevice.Usingchannelmarkersdifferstoanalogueor
digitaloutputsorCOMchannelssettooutputs,inthataccessistothedeviceitself
andnotjusttotheconnectedprocess.
Thecreatedmarkerisconfiguredasasourceforthecontrollingchannel,e.g.asa
resettriggerforacounterchannel.
Application:ThisoptionenablesmarkercontrolviatheDataServiceConfiguratoror
ProfiSignal.Youcansetthemarkertoaconstantvalueviathemarker'scontext
menuintheDataServiceConfiguratororcontrolthevalueautomaticallyviaan
applicationofProfiSignal.
118
