ProfiMessage
Input value A Input value B Output value
L H L
H L L
H H L
Status table XOR (exclusive OR)
Input value A Input value B Output value
L L L
L H H
H L H
H H L
Status table XNOR
Input value A Input value B Output value
L L H
L H L
H L L
H H H
Status table antivalence
Theoutputforantivalenceisthen"High"ifanoddnumberofinputsare"High"
andtheremaininginputsare"Low".
Input value A Input value B Input value C Output value
L L L L
L L H H
L H L H
L H H L
H L L H
H L H L
