ProfiMessage

Inversion
Activateslogicalinversion.
9.3.1.8 Configuration/settingsforcounter
ReferalsotothetechnicalspecificationsforthecounterandthesectiononMeas-
uringfrequencyandrotationspeed.
The(measuringfrequencyorcountingpulses)modeissetintheRotation speed
measurementtab.Refertoconfiguration/settingsforI/Omodule.
Unit
ThepresetunitforfrequencymeasuringisHz.Entertherequiredunithere.
Main settings tab
301
