ProfiMessage
l ModbusRTUmaster
l ModbusRTUslave
l ModbusRTUchannel
l User-definedprotocol
l User-definedinputchannel
l User-definedoutputchannel
4.8.3.1 PROFIBUSprotocol
You must run the COM connection in the PROFIBUS
interface mode and set the PROFIBUS address there
(see COM connection).
CreatethePROFIBUSprotocolchannelviathecontextmenuoftheCOMcon-
nection:Create channel → PROFIBUS protocol.

WerecommendgivingauniqueChannel name,amendingtheDescriptionand,if
necessary,enteringtheLocation.
Main settings tab
UseSlave redundancy tosetuparedundantPROFIBUSinterface.Theinterfaceis
usedonlywhentheintendedinterface(COM1)fails.
l SelectNone ifredundancyisnotrequired.
l SelectPNO_2212_V1.2tosetuparedundantPROFIBUSinterface.
AredundantPROFIBUSinterfacecanbeconfiguredwiththissettingin
accordancewiththeproceduredescribedinPNODocumentNo.2212V1.2of
November2004fromtheGermanPROFIBUSUserOrganization(PNO).
l TheCustom1orCustom2optionisreservedforcustomer-specificenhance-
ments.
