Delphin ProfiMessage User Manual

ProfiMessage
Youcanenteronlyoneendsequence.Multipleendsequencesarenotpos-
sible.
l Transmission pause
Enterthepauselengthin“charactertimes”(timedurationfortransmission
ofacharacterviainterface)afterwhichamessageshouldbeconsideredas
ended.
Decimal separator
Enterthedecimalseparatorhereforthetransmissionofnumerics.Thecharacter
willbeusedforallchannelswhichtransmitnumerics.
4.8.3.4.1 Creatinguser-definedprotocol
UsetheMain settingstabtoenterthegeneralsettingsfortheinterface(baudrate,
numberofdatabitsetc.)fortherelevantCOMinterface.RefertoCOMinterface,
UARTsettings.
Createtheuser-definedprotocolviatheCOMinterface'scontextmenu:Create
channel→  User-defined protocol.

4.8.3.4.2 User-definedoutputchannel
CreateanoutputchannelviathethecontextmenuforUARTGenericProtocol:
192
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
