Delphin ProfiMessage User Manual

ProfiMessage
Forasingleidealline(sinewave),thetotalvalueandeffect-
ivevaluematch.
9.2.5.17 “Residualvalue”
TheDSPdetermines(calculates)aweightedsumofallquadraticlinesofthefre-
quencyspectrum,excludingthethreeharmoniccomponentsand,whenapplic-
able,afreelydefinablecomponentofchoice.
Thischaracteristicvaluecanbedeterminedonlywhenacyclical
digitalpulseisconnectedtoadigitalinput/counter(e.g.thepulse
fromarotatingshaft).Thissignalprovidesthebasicfrequencyfn.

Acquisitionofanaccuratefnviathedigitalfrequencyinputisessen-
tial,asisthehighestpossibleresolutionforthefrequencyspectrum.
Intheeventofdeviationsbetweenthemeasuredfrequencyandfre-
quencyspectrum'slineindex,evaluationofthenextlinetakesplace.
275
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
