ProfiMessage
Galvanic
isolation
1kV
8.2 I/O modules: AAST, ADGT, ADIT and ADVT

Analogueinputs
Numberofinputs
AAST:4
ADGT:8
ADIT:10
ADVT:15
Connections Terminals,max.diameter2.5mm2
Voltagemeasuring
ranges
±156mVto±10V(bipolar)and+156mVto+10V(uni-
polar)
Currentmeas-
urementranges
±20mA,0...20mAand4...20mA
Currentmeasurementrequiresaloadresistanceof10...
500Ω
Samplingrate
AAST,ADITandADVT:Max.of600measurements/s
ADGT:Max.60measurements/s
Sequentialsampling,A/Dmeasurementtimeforeach
channelindividuallyadjustable
Resolution 24bits(about7decimaldigits)
Inputimpedance >1GΩ,withADGT>10MΩ
Measurementerror
(DC)
Voltage/current:
±0.01%ofmeasurement
range/endvalue
Pt100: ±0.1K
Pt1000 ±0.1K
Thermocouples:
±0.1%ofendvaluefollowingcom-
pensation
Thermocouples
Built-incoldjunction,externaloptional
NiCr-NiAl(K),NiCr-CuNi(E),NiCrSi-NiSi(N),Fe-CuNi(L),
Fe-CuNi(J),Pt10Rh-Pt(S),Cu-CuNi(U),Pt13Rh-Pt(R),
Cu-CuNi(T),Pt30Rh-Pt6Rh(B),W5Re-W26Re(C)
Measuringranges-270°C...2320°C,dependingonther-
mocouple
Resistance
Pt50toPt5000,Ni50toNi5000,YSI400
223
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
