4 Wire:Therecommendedconnectionmethodforlowimpedancesensorsand/or
longersupplylines.Thelossoffeedlinesdoesnotmatterbecausethedevicehasa
high-ohminputresistance(novoltagedroponthelinefeed)andthevoltagedrop
(themeasurementvalue)canbemeasureddirectlyatthesensor.
ThereisnochoiceofcircuittypeforYSI400
sensors.
4.6.3.6 Thermocouplesensortype

TheexampleshowsthesettingsforatypeKthermocouple(NiCr-NiAl,nickel-
chromeandnickel-aluminiumalloy).
Sensor type
Selectyourthermocoupletype.Thelettertypeandmaterialtypeofthether-
mocouplewiresaregiven.
Measuring range
Themaximumpossiblesensormeasuringrangeispre-selected.Thechannel
receivesthestatus‘Measurementrangeoverrun/underrun’formeasurementsnot
withintherange.Channelstatusvaluesareavailableinstatusmonitoring.
