Delphin ProfiMessage User Manual

ProfiMessage
l Timeout
Setsthemaximumpermissibletimethatmayelapsebetweenaquery(poll
string)anditsresponse,orbetweentwosequentialresponses(withoutpoll
string)beforeanerrorstatusisgiven.Intheeventofanerror,a"wire-
break"statusisdisplayed(referalsotothetableinStatusmonitoring).
l Pause
Setsthewaitingtimebetweentwoqueriesusingapollstring.Thepollstring
isresentoncethistimehaselapsed.
Polled
l Poll string
Thestringenteredherewillbesenttotheuseraccordingtothetimeframe
definedusingPause.Thisisrequiredwhenausersendsaresponse(a
value)onlyafterhehasbeen“prompted".Leavethefieldemptyiftheuser
doesn'trequirepromptingtosend.
Enterthestringastext.ASCIIcharactersthatcannotbeentereddirectly,
e.g.carriagereturn(CR)orlinefeed(LF),canbeenteredusing%andthe
ASCIIvalueinhexadecimalformat:EnterCRas%0DandLFas%0A.
l Filter
Iftheusersendsmultipleresponses(messagesorcomments),youcanuse
afiltertoretrievetheresponsesyourequireinthischannel.Enterthemes-
sage'sbeginning,e.g.$GPGGA.
l Delimiter
Ifthefilteredmessagecontainsmultipleelements,usethisdelimiterto
determinehowtheseelementsareseparatedandwhichelement(n’th ele-
ment)istobeusedforthischannel.
Decoding
l Offset
TruncatesthefirstcharacterofthemessageassetunderPolled.Thismeans
themessageisevaluatedfromthisoffset.Youcansettheoffsetfromthe
absolutebeginningofthemessage(default)orrelativetothefirstcharacter
withtheFilter(Offset relative to filter).
l Maximum length
Evaluatesthemessageonlyuptothecharactergivenhere.Allotherchar-
actersareignored.
4.8.4 LAN
Thiswindowenablesnetworkdatatobeinputoramended.Changestosettings
areonlyadoptedafterclickingSave .
203
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
