ProfiMessage
Pickup delay:Thetimerchannelstartsthedelaytimewhenthesourcechangesto
theactivestate(High levelorLow leveltrigger).Attheendofthedelaytime,the
timeroutputswitchesintoanactivestate("On")solongasthesourceretainsthe
activestate.Ifsource'sactivestateisshorterthanthedelaytime,noreaction
takesplacewiththetimeroutput.
Dropout delay:Theoutputofthetimerchannelbecomesactive("On")whenthe
sourceswitchestoanactivestate(High levelorLow leveltrigger)oredgetrig-
gering(Rising edge,Falling edgeorEdges (both)triggers).Thesameedgeorthe
switchofthesourcefromactivebacktoinactivestartsthedelaytime.Attheendof
thedelaytime,thetimer'soutputbecomesactive("Off").
Theimageshowsthesignalofadropoutdelaywithleveltriggering(Lowlevel).
Retriggerable:Thisoptionenablesarestartofthedelaytimeviaothersourcetrig-
gereventsduringthedelaytime.
Source:Specifythedelaychannelhereandwhichlevelorwhichedgeistobe
delayed.
159
Delphin Technology AG
Dezember 2015
ProfiMessage Manual
