OPERATION
4 Issue 1January 2008 (99)
as North,
l appear, and
bination with the anchor point
(4) Rotation
The field can be rotated to 0, 90,180 and 270 degrees. Directions are stated
South, East and West. By pressing on a direction, a dropdown menu wil
the user can then select the desired rotation. In com
(see page 100) the field can be rotated to suit requirements.
dden during printing, i.e. it will not be Printed.
t
mposite component.
Use the Separator height to define the separation thickness between the ordinary
barcode and the 2d component.
The separator height must be between pixel size and 2 times pixel size.
(7) Pixel Size
GS1 DATABAR and Datamatrix codes do not use the Scale Requested
parameter. Instead, the size of the narrow bars (or squares) can be defined
with this number.
(5) Phantom
Allows the item to be hi
(6) Separator Heigh
GS1 DATABAR barcodes have the option of having a 2d co
2d Com
onent
Se
arato
2786
