EDAN elite V6 User Manual

Patient Monitor User Manual Product Specifications
- 266 -
Data Sample Rate 20 data frames, 420 bytes, per second
Respiration Rate 0 to 150 ± 1 breaths/min
Fi and ET Fi and ET are displayed after one breath and have a continuously
updated breath average.
ET will typically decrease below nominal value (ET
nom
) when
respiration rate (RR) exceeds the RR threshold (RR
th
) according to the
following formulas:
CO
2
N
2
O, O
2
, DES, ENF, ISO , SEV
HAL
NOTE: Measured at I/E ratio 1:1 using breath simualtor according to
EN ISO 80601-2-55 fig. 201.101
Measurement Range CO
2
: (0 to 25) vol%
O
2
: (0 to 100) vol%
N
2
O: (0 to 100) vol%
HAL, ENF, ISO, SEV, DES: (0-25) vol%
AwRR: 0 rpm to 150 rpm
Resolution CO
2
: 0.1%
HAL, ENF, ISO, SEV, DES: 0.1%
N
2
O: 1%
O
2
:1%
AwRR: 1 rpm
☆
Accuracy-
Standard
Conditions
Gas Range Accuracy
CO
2
(0 to 15) vol%
(15 to 25) vol%
± (0.2 vol% + 2% of reading)
Unspecified
N
2
O (0 to 100) vol% ± (2 vol% + 2% of reading)
HAL, ENF, ISO (0 to 8) vol %
(8 to 25) vol %
± (0.15 vol% + 5% of reading)
Unspecified
SEV (0 to 10) vol %
(10 to 25) vol %
± (0.15 vol% + 5% of reading)
Unspecified
DES (0 to 22) vol %
(22 to 25) vol %
± (0.15 vol% + 5% of reading)
Unspecified
O
2
(0 to 100) vol % ± (1 vol% + 2% of reading)
