S600+ Instruction Manual
Revised July-2017 Troubleshooting 8-1
Chapter 8 – Troubleshooting
In This Chapter
8.1 Guidelines ......................................................................................... 8-1
8.2 Checklists .......................................................................................... 8-2
8.2.1 Power Issues ........................................................................ 8-2
8.2.2 Startup Menu ........................................................................ 8-2
8.2.3 Front Panel Lighting ............................................................. 8-2
8.2.4 Front Panel LED................................................................... 8-2
8.2.5 I/O LED ................................................................................ 8-3
8.2.6 I/O Fail Messages ................................................................ 8-3
8.2.7 Serial Communications ........................................................ 8-3
8.3 Procedures ........................................................................................ 8-3
8.3.1 Reflash Firmware ................................................................. 8-4
8.3.2 Send and Reflash the Config File ........................................ 8-4
8.3.3 Clear SRAM ......................................................................... 8-5
8.3.4 Changing the Fuse ............................................................... 8-6
This chapter provides instructions for maintaining and troubleshooting
the S600+. If you still experience difficulties after using the
troubleshooting procedures in this section, please contact your local
sales representative or technical support personnel.
8.1 Guidelines
When attempting to diagnose a problem with an S600+:
 Remember to write down what steps you have taken.
 Note the order in which you remove components.
 Note the orientation of the components before you modify or
remove them.
 Read and follow all cautions in this manual.
Before you contact your local sales representative or technical support
with a problem, first check the following:
 Are all the modules seated correctly and the retaining screws
fastened?
 Is all the field wiring properly connected?
 Is the supply voltage correct?
When you are done troubleshooting, perform a warm start or cold start
(see Chapter 7, Startup).
If your local sales representative or technical support instructs you to
return the S600+, replace the troubled parts with spares and return the
troubled parts to the address given by the local sales representative or
technical support.
