S600+ Instruction Manual
Revised July-2017 Chromatographs C-11
C.4.2 Determining the Mole Percentage Set
This section details how the module selects the mole percentage set.
Keypad
Set Selected
Refer to Section C.3, Configuration Type: Keypad Mole Percentage
Set Only, for information on setting the keypad percentage set.
Chromatograph
Set Selected
The system uses the following logic to select a chromatograph set:
If the current report has no deviations or critical alarms, then
Copy the latest real RD into the Real RD.Chromat field.
Copy the latest real CV into the Real CV.Chromat field.
Copy the latest mole % set to the in-use mole % set.
Else
If the revert switch is set and a previous report is OK then
Copy the last good real RD to the Real RD.Chromat field.
Copy the latest real CV to the Real CV.Chromat field.
Copy the last good mole % to the in-use mole % set.
Else
Switch to using the keypad mole % set.
Endif
C.4.3 Handling Operator Commands
This section details how the module handles operator commands.
Select Keypad Mole
Percentage
Select the keypad set only if it is valid according to the checks outlined
in Section C.4.2, Determining the Mole Percentage Set. Otherwise,
leave the in-use set intact.
Select Chromat Mole
Percentage
The system uses the following logic to select a chromat mole
percentage
If there are no system alarms and the latest report is OK, then
Copy the latest mole % set to the in-use set
Else
If the Revert to Last Good switch is on then.
If the prevous report is OK then.
Copy the latest mole % set to the in-use set.
Copy the latest RD and CV to the in-use set.
Endif
Endif
Endif
C.5 Configuration Type: 2251/2350 USA
For this configuration, use PCSetup to preconfigure the master Modbus
interface. The master Modbus process interfaces to the 2251/2350 as
instructed by the chromatograph data handling software. The system
can then perform a controlled, sequential series of polls, which enables
the orderly acquisition of analysis report data.
Note: The process of configuring a 2251 and 2350 USA
chromatograph is identical. For that reason, we use 2251 to
refer to both the 2251 and 2350 device.
Keypad Mole
Percentage Set
Refer to Section C.3, Configuration Type: Keypad Mole Percentage
Set Only, for information on setting the percentage set.
