Revised July-2017 Front Panel Navigation B-3
B.3 Totals Menu
The system uses all parameters in this group in calculating the various
totals. If one of the streams is a prover, the stream does not appear on
this menu.
1* STATION 1
2* STATION 2
3* STREAM 1
4* STREAM 2
5* STREAM 3
Main > Totals Menu
1. STN01 NRM UVOL
2. STN01 NRM CVOL
3. STN01 NRM MASS
4. STN01 NRM ENERGY
5. STN01 FLT UVOL
6. STN01 FLT CVOL
7. STN01 FLT MASS
8. Next
1. Previous
2. STN01 FLT CVOL
3. STN01 FLT MASS
4. STN01 FLT ENERGY
5. STN01 NRM PREM
6. STN01 FLT PREM
Station 1 (Gas)
1. STN02 GUVOL
2. STN02 GSVOL
3. STN02 MASS
4. STN02 IVOL
Station 2 (Liquid)
1. STR01 NRM UVOL
2. STR01 NRM CVOL
3. STR01 NRM MASS
4. STR01 NRM ENERGY
5. STR01 FLT UVOL
6. STR01 FLT CVOL
7. STR01 FLT MASS
8. Next
1. Previous
2. STR01 FLT CVOL
3. STR01 FLT MASS
4. STR01 FLT ENERGY
5. STR01 NRM PREM
6. STR01 FLT PREM
Stream 1 (Gas Turbine) Stream 2 (Gas DP)
Stream 3 (Liquid Coriolis)
1. STR02 FWD UVOL
2. STR02 FWD CVOL
3. STR02 FWD MASS
4. STR02 FWD ENERGY
5. STR02 REV UVOL
6. STR02 REV CVOL
7. STR02 REV MASS
8. Next
1. Previous
2. STR02 REV CVOL
3. STR02 REV MASS
4. STR02 REV ENERGY
5. STR02 FWD PREM
6. STR02 REV PREM
1. STR03 GUVOL
2. STR03 GSVOL
3. STR03 MASS
4. STR03 IVOL
8. STR03 PULSE
