Emerson FloBoss S600+ User Manual

S600+ Instruction Manual
Revised July-2017 Front Panel Navigation B-7
B.8 Calculations Menu
The parameters in this group are all used in and result from system
calculations and are further subgrouped as parameters relating to the
values going into the calculations (as input) and results of the
calculations (as output).
3* STREAM 1
4* STREAM 2
5* STREAM 3
Main > Calculations Menu
(Empty screen)
Station 1 (Gas)
(Empty screen)
Station 2 (Liquid)
1* AGA 7
2* KF/MF LIN
3* ISO6976
4* AGA 8
Stream 1 (Gas Turbine) Stream 2 (Gas DP)
1* DOWN/UP CORR T/P
2* UPSTREAM EXP
3* ISO5167
4* PIPE CORRECTION
5* ISO6976
6* AGA 8
7* ISOTR9464
1* KF/MF LIN
2* BASE TO MTR
3* SEL TO BASE
Stream 3
1. INPUTS
2. OUTPUTS
AGA 7 (STR01)
1. INPUTS
2. OUTPUTS
KF/MF LIN (STR01)
1. INPUTS
2. OUTPUTS
ISO6976 (STR01)
1. INPUTS
2. OUTPUTS
AGA 8 (STR01)
1. INPUTS
2. OUTPUTS
DOWN/UP CORR T/P
(STR02)
1. INPUTS
2. OUTPUTS
UPSTREAM EXP (STR02)
1. INPUTS
2. OUTPUTS
ISO5167 (STR02)
1. INPUTS
2. OUTPUTS
PIPE CORRECTION
(STR02)
1. INPUTS
2. OUTPUTS
KF/MF LIN (STR03)
1. INPUTS
2. OUTPUTS
BASE TO MTR (STR03)
1. INPUTS
2. OUTPUTS
SEL TO BASE (STR03)
1. INPUTS
2. OUTPUTS
ISO6976 (STR02)
1. INPUTS
2. OUTPUTS
AGA 8 (STR02)
1. INPUTS
2. OUTPUTS
ISOTR9464 (STR02)
