S600+ Instruction Manual
C-2 Chromatographs Revised July-2017
 Siemens
 Generic (user-configurable)
Note: This software does not currently support a paycheck
chromatograph.
C.1 Station/Stream Assignment
The S600 chromatograph software supports the following station and
metering stream combinations:
 Single stream with no station
 Multiple metering streams assigned to a common station (where
each stream uses the station’s mole percentage set)
 Individual metering streams in the same S600+ (where each
metering stream connects to the same chromatograph but each
metering stream maps to a unique chromatograph cycle stream)
 Multiple S600+s connected to a single chromatograph (using a
router which is itself connected to the chromatograph).
The following sections describe each of the station and metering
stream combinations.
C.1.1 Single Metering Stream with No Station
This situation uses the single Modbus map that PCSetup generates in
conjunction with the chosen chromatograph type and processing
options. The identified S600+ chromatograph “cycle stream” must
match the reported chromatograph stream.
Mode Handling
Note
The stream’s relative density (RD) and heating value (CV) modes
(provided they are in “keypad” or “chromat” mode) can track the mole
percentage selection (keypad or chromat).
C.1.2 Multiple Metering Streams Assigned to a Common Station
This situation uses the Modbus map that PCSetup generates to describe
the station data which is then passed to any of the metering streams
which are assigned to the same station and have their acceptance type
set to “station copy”.
The module acquires and processes the station’s mole percentage set,
RD, and CV, and then copies the processed good data into the
equivalent data points for any dependent streams.
Mode Handling
Note
The station and stream’s RD and CV modes (provided they are in
“keypad” or “chromat” mode) can track the mole percentage selection
(keypad or chromat).
C.1.3 Individual Metering Streams Assigned to a Chromatograph
Each metering stream may have an individual serial connection to a
chromatograph. Generate an individual Modbus map for each
connection.
