S600+ Instruction Manual
C-4 Chromatographs Revised July-2017
C.2.1 Main Setup Parameters
Combination Type
Keypad set only /single chromatograph
Split Switch
None/C6+/C7+/C8+/C9+/C10+
Range Checks
Disable/enable mole percentage range alarm
handling
Deviation Checks
Disable/enable mole percentage deviation
checking
Critical Checks
Disable/enable critical alarms checks
Non Critical Checks
Disable/enable non-critical alarms checks
Failure Revert
Keypad/last good set revisions upon failure
Acceptance Type
Accept and copy
Accept, normalise, and copy
Automatic normalise and copy
C.2.2 Component Set Selection Inputs
Set Selected
Keypad or chromat (or keypad after failure)
Default Mole Set
Keypad set of component mole percentages
Additionals
Keypad values for H
2
S,H
2
O,He,O
2
,CO,and H
2
C6+ etc. Splits
Percentages of C6+ for hexane through to
decane
Low Limits
Low alarm bands for component mole
percentages
High Limits
High alarm bands for component mole
percentages
Deviation Limits
Percentage change limits for current versus
previous reports
Accept Command
For validation/acceptance of the keypad set
C.2.3 Component Set Selection Outputs
In use mole %
Value of the mole percentage selected
Real Relative Density
As reported from the chromatograph
CV
As reported from the chromatograph
C.2.4 Telemetry Configuration Parameters
Status
Announces telemetry alarms; is fixed at pay.
Type
See Introduction to this appendix.
Port
Indicates the S600+ telemetry port number
Address
Indicates the telemetry address of slave
chromatograph
Cycle Stream
Identifies the chromatograph analysis stream
Analysis Timeout
Reserved for future use
Mole Ordering
Mole ordering is based on the S600+ internal
order for component codes and specifies the
slot in the telemetry buffer for this component’s
mole percentage value. This ordering array is
normally updated upon receipt of the
component codes from the chromatograph.
Poll Delay
Indicates the interval between polls
