S600+ Instruction Manual
Revised July-2017 I/O 4-15
Table 4-13. I/O Module Jumper Settings
Jumper
Position
Descriptions
Flash
LK1
ON
Flash Write Enable
OFF
Flash Write Protected
Node Address (see Table 4-14)
LK2
ON
Point to Point mode enabled
OFF
Point to Point mode disabled
LK3 – LK10
Multiplex (MUX) Addresses – see Table 4-14
LK11
ON/OFF
Communications Mode – Off is only supported option
LK12
ON/OFF
Oscilloscope Earth
LK13, LK14, LK15
Not Used
A/D Converter Shunts
LK16
1
ON
ADC CH1 – Current Mode
OFF
ADC CH1 – Voltage Mode
LK17
1
ON
ADC CH2 – Current Mode
OFF
ADC CH2 – Voltage Mode
LK18
1
ON
ADC CH3 – Current Mode
OFF
ADC CH3 – Voltage Mode
LK19
1
ON
ADC CH4 – Current Mode
OFF
ADC CH4 – Voltage Mode
LK20
1
ON
ADC CH5 – Current Mode
OFF
ADC CH5 – Voltage Mode
LK21
1
ON
ADC CH6 – Current Mode
OFF
ADC CH6 – Voltage Mode
LK22
1
ON
ADC CH7 – Current Mode
OFF
ADC CH7 – Voltage Mode
LK23
1
ON
ADC CH8 – Current Mode
OFF
ADC CH8 – Voltage Mode
LK24
1
ON
ADC CH9 – Current Mode
OFF
ADC CH9 – Voltage Mode
LK25
1
ON
ADC CH10 – Current Mode
OFF
ADC CH10 – Voltage Mode
LK26, LK27, LK28
Cannot be changed.
LK29, LK30
1-2/2-3
Open Collector Mode (2-3). 2-3 is only supported option.
Frequency Output Modes
LK31
ON
FRQ 01 – DC Coupled
OFF
FRQ 01 – AC Coupled
LK32
ON
FRQ 02 – DC Coupled
OFF
FRQ 02 – AC Coupled
LK33
ON
FRQ 03 – DC Coupled
OFF
FRQ 03 – AC Coupled
1
A/D Converter Shunts are configured in groups of five and must be used together as current or voltage. Fit
LK16 through LK19 as a set. Fit LK21 through LK25 as a set.
