S600+ Instruction Manual
4-24 I/O Revised July-2017
4.2.6 Jumper Settings
The boldface entries in the Position column on Table 4-22 are the
default configuration settings. They may not apply to your specific
configuration.
Table 4-22. Prover Module Jumper Settings
Jumper
Position
Descriptions
Flash
LK1
ON
Write Enable
OFF
Write Protected
Node Address (see Table 4-23)
LK2
ON
OFF
Multiplexed mode (MUX)
LK11
ON
OFF
Multiplexed mode (MUX)
MUX Address:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
LK3
●
●
LK4
●
●
LK5
●
●
LK6
●
●
LK7
●
●
LK8
●
●
LK9
●
●
LK10 1-2
●
●
●
●
●
●
●
2-3
●
●
●
●
●
●
●
Altera Voltage
LK12
1-2
3.465V
2-3
5V - Vcc
Raw Pulse Output Mode (currently not supported)
LK13/14
1-2
RS-422 differential driver
2-3
Open collector
Raw Pulse Input #3 – Line Determination
LK15/16
ON
Line determination resistors connected: +ve pulled up to Vcc and –ve down to 0V
OFF
Lines undetermined
Table 4-23. Node Addressing: Communications Mode Selection
Mode
Link 2
Link 11
Link 3-10
Point-to-point
ON
OFF
IGNORED
Multi-dropped
ON
ON
IGNORED
Multiplexed (MUX)
OFF
OFF
ADDRESS
