S600+ Instruction Manual
B-4 Front Panel Navigation Revised July-2017
B.4 Operator Menu
The parameters in this group are values and statuses you typically want
to view when monitoring the operation of the S600+.
Note: AVE T&P refers to the average temperature and pressure
parameters. STAT&CTRL refers to status and control
parameters.
1* STATION 1
2* STATION 2
3* STREAM 1
4* STREAM 2
5* STREAM 3
6* STREAM 4
Main > Operator Menu
1. AVE T&P
2. STAT&CTRL
Station 1 (Gas)
1. AVE T&P
2. STAT&CTRL
3. SEQUENCE CTL
4. FBAL CTL
5. PROVER IO
6. RUN CTL
7. RUN STATUS
8. Next
1. Previous
2. CONSTANTS
3. STREAM DATA
4. HALF RUN
5. FULL RUN
6. FINAL RUN
7* VALVES
Station 2 (Liquid)
1. KF/MF LIN
2. STREAM SETUP
3. STREAM STATUS
4. METER SETUP
5. METERING IO
6. CALCULATED DATA
7. FWD AVG DATA
8. Next
1. Previous
2. CALCULATED DATA
3. FWD AVG DATA
4. REV AVG DATA
5. COMPOSITION
6. FLOW SWITCHING
Stream 1 (Gas Turbine) Stream 2 (Gas DP)
1. STREAM SETUP
2. STREAM STATUS
3. METER SETUP
4. METERING IO
5. CALCULATED DATA
6. FWD AVG DATA
7. REV AVG DATA
8. Next
1. Previous
2. FWD AVG DATA
3. REV AVG DATA
4. COMPOSITION
5. PIPE CORRECTION
6. FLOW SWITCHING
1. KF/MF LIN
2. PROVED DATA
3. SETUP
4. STATUS
5. METER SETUP
7. CALCULATIONS
8. Next
1. Previous
3. CALCULATIONS
4. BASE TO MTR
5. SEL TO BASE
6. COR IO
7. FLOW SWITCHING
Stream 3 (Liquid Coriolis)
