S600+ Instruction Manual
3-2 CPU Module Revised July-2017
Figure 3-1. CPU Module Backplate
Figure 3-2. CPU Module
TB-1 Power
First Ethernet port
COM 3
COM 4
Four additional RS-485
ports (COM 9 through
COM 12)
USB port
Second Ethernet port
COM 5
COM 6
COM 7
Note: You can configure
the A () terminal of COM
12 as a digital input
Backup
battery
Ejector
latches
