S600+ Instruction Manual
C-6 Chromatographs Revised July-2017
Raw Mole %s
Updated from a successful telemetry poll
Raw CV (etc.)
Updated from a successful telemetry poll
Latest Mole %s
Adjusted/normalised from latest report
Last Good Mole %
Adjusted/normalised from latest report
Raw Alarms Register
Detailed indication of global alarms
Codes Request Flag
Trigger for Modbus master telemetry module
Component Codes
Updates from a successful telemetry poll
Last Good Set of Mole
%s
S600+-internally ordered from last good raw
set
Time Stamp
Time of the last good analysis
C.3 Configuration Type: Keypad Mole Percentage Set Only
Use this configuration when there is no chromatograph linked to the
S600+. The keypad set describes the entire mole percentage
breakdown, including additionals and C6+ entries. Thus, whenever you
use the keypad set, the system ignores the entries from the other arrays
for additionals and C6+ and uses the keypad set alone.
Processing of the keypad set and its subsequent copying into the in-use
set depends on the acceptance type:
Accept and Copy
The sum of the keypad components is regularly maintained. When the
Accept command is issued:
 If range checking is enabled, the keypad set is checked against
individual mole percentage low and high limits.
 If range checking is disabled, the keypad sum is checked for the
range 99.9 to 100.1.
 If the keypad set is valid, the system copies it to the in-use set.
 If the keypad set is invalid, an alarm is raised and the in-use set
remains intact.
Accept, Normalise, and
Copy
The sum of the keypad components is regularly maintained. When the
Accept command is issued:
 If range checking is enabled, the keypad set is checked against
individual mole percentage low and high limits.
 If range checking is disabled, the keypad sum is checked for the
range 99.9 to 100.1.
 If the keypad set is valid, the system normalises it and then copies
it to the in-use set
 If the keypad set is invalid, an alarm is raised and the in-use set
remains intact.
Auto Normalise
The sum of the keypad components is regularly maintained. On a
regular basis:
 If range checking is enabled, the keypad set is checked against
individual mole percentage low and high limits.
 If range checking is disabled, the keypad sum is checked for the
range 99.9 to 100.1.
