Emerson FloBoss S600+ - Changing a Display Value

S600+ Instruction Manual
5-10 Front Panel Revised July-2017
3. Press a numeric key to select a value. The left-hand screen in
Figure 5-11 displays.
4. Press a numeric key to confirm the selected value. The right-hand
screen in Figure 5-11 displays, showing the new value.
CONFIRM
SET TO:
I/O
1. YES
2. NO
STR01 DENS SELECT
Status:
I/O *
P19.1 <of 11>-------
Figure 5-11. Changing a Display Option
Note: This option is not available if the status bar shows W,
indicating that the webserver is active.
5.7 Changing a Display Value
You can change the value of any displayed S600+ parameter marked
with an asterisk.
To change a value:
1. Locate the display (shown at the left-most side of Figure 5-12) and
press CHNG. The middle screen in Figure 5-12 displays.
2. Enter a valid security code. Once you enter a valid code, the screen
on the right-most side of Figure 5-12 displays.
ADCO2
I/O01 ADC 02
Keypad Value:
100.000 !*
Measured Value:
-24.998 !
P27.2 <of 4>---------
ADCO2
I/O01 ADC 02
Keypad Value:
Enter Code:----------
Measured Value:
-24.998 !
P27.2 <of 4>---------
CURRENT VALUE:
100.000 !
NO ENTRY LIMITS:
ENTER NEW VALUE:
Figure 5-12. Changing a Display Value
3. Enter the new value (in this example, 99.999). It appears on the
display as shown in the left-hand screen of Figure 5-13.
Note: While in Change mode, you can use ◄ to delete digits or
characters by backspacing over the displayed data. You
can also press CLEAR at any time to abort the current
operation or task.
