S600+ Instruction Manual
Revised July-2017 General Information 1-1
Chapter 1 – General Information
In This Chapter
1.1 Scope of Manual ................................................................................... 1-1
1.2 FloBoss S600+ Flow Computer ............................................................ 1-2
1.3 Config600 Configuration Software ........................................................ 1-5
1.3.1 Config600 Lite ........................................................................ 1-6
1.3.2 Config600 Lite Plus ................................................................ 1-6
1.3.3 Config600 Pro ........................................................................ 1-7
1.4 Additional Technical Information .......................................................... 1-8
1.4.1 Open Source Software ........................................................... 1-8
This manual covers the installation and startup procedures (including
basic maintenance, operation, and troubleshooting) for the FloBoss
™
S600+ flow computer (the “S600+”). For information about
Config600
™
, the PC-based configuration software for the S600+, refer
to the Config600 Software User Manual (Part D301220X412).
This manual focuses on the S600+, the enhanced version of the S600
with a new CPU module. Refer to technical specification FloBoss
S600+ Flow Computer (S600+) for technical information.
Note: Use of this equipment in a manner not specified by Remote
Automation Solutions may impair the protections the
equipment provides.
This chapter details the structure of this manual and provides an
overview of the S600+ and its components.
1.1 Scope of Manual
This manual contains the following chapters:
Chapter
Contents
Chapter 1
General Information
Provides an overview of the S600+ and its
configuration software (Config 600).
Chapter 2
Installation
Provides instructions on installing the S600+
housing, as well as installation preparation and
panel mounting procedures. This chapter also
describes the installation and removal of the plug-in
modules.
Chapter 3
CPU
Describes the use of the communications and power
connector blocks, field wiring configurations, and
jumper settings for the CPU module.
Chapter 4
Input/Output (I/O)
Describes the use of the plug-in connector blocks,
field wiring configurations, and bit link settings for
the I/O modules.
Chapter 5
Front Panel
Describes the front panel keypad, communications
port, and display area. This chapter also shows how
you access the S600+ through the front panel
display, including keypad functions, screen displays,
display navigation basics, data entry, and report
printing.
