Revised July-2017 Chromatographs C-5
Matched Reset Delay
Indicates the interval after receipt of a matched
report before resetting the new data flag
Unmatched Reset
Delay
Indicates the delay the system takes before
resetting the new data flag after the flag is
seen as set but the report cycle stream does
not match the S600+.
Note: If this value is set to zero, then the
sequence does not rest the non-matched new
data flag.
C.2.5 Telemetry Outputs
Stage Number
Any one of the following values:
0
Idle
1
Poll delay, then poll for status data
2
Wait for status data
3
Poll delay, then poll for component
codes
4
Wait for component codes
5
Poll delay, then wait for mole
percentages
6
Wait for mole percentage data
7
Poll delay, then wait for CV, RD
8
Wait for CV, RD
9
Reset new data flag (reserved)
10
Poll delay, then poll again for status
data
11
Wait for status data
12
Process analysis data
13
Delay after a matched report, then poll
again for status data
14
Wait for new status data
15
Poll delay, then reset new data flag
16
Wait for new data flag reset
17
Delay after unmatched report, then poll
again for status data
18
Wait for status data
19
Poll delay, then reset new data flag
20
Wait for new data flag reset
Status Poll Request Flag
Trigger for Modbus master telemetry module
Mole Codes Request
Flag
Trigger for Modbus master telemetry module
Mole Poll Request Flag
Trigger for Modbus master telemetry module
CV (etc.) Poll Request
Flag
Trigger for Modbus master telemetry module
Reset Report Flag
Trigger for Modbus master telemetry module
Current Report Status
Accepted or rejected
Good Report Latch
Flat for receipt of a good report
Raw Status Data
Updated from a successful telemetry poll
